| Model | NLC-8000M |
|---|---|
| Output power | 320 W |
| Power supply | 100–120 VAC / 200–240 VAC |
| Microphone capacity | ≤8000 wired units, 3 Extension units |
| Frequency response SNR | 20 Hz – 20 kHz |
| Dynamic range | >78 dB(A) |
| THD | >80 dB <0.05% |
| Output & Interface | >1 kΩ load, PC control supported |
| Idle power consumption | 30 W |
| Wired microphone connection | Dedicated 8-pin cable |
| Standards | IEC 60914 |
| Touch panel | 5.0-inch capacitive touchscreen |
| Color | Black |
| Net weight | 5.6 kg |
| Dimensions (L × W × H) | 484 × 303 × 88 mm |
| Installation | 19-inch standard rack |
Full-Function Digital Conference Main Unit NLC-8000M
The 2U digital conference main unit uses clock synchronization and high-speed transmission technology. It features a built-in DSP processor for feedback suppression and a digital EQ module for audio balancing. Supports Phoenix, XLR, and RCA I/O, with microphones connected via 8-pin or RJ45 ports. Includes a built-in control module and programmable network platform for external device control. Supports video input for camera tracking and split-screen display.
