| Input | 16 Channels: 1 to F inputs, EMC2 (for emergency paging) |
| Output | 16 Channels: (1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16 outputs) |
| Frequency Response | 60Hz – 16KHz (+/- 3dB) |
| S/N | NA |
| THD | NA |
| Indicators | LCD Display, power LED |
| Protection | AC Fuse : 0,5A |
| Power Consumption | 15 – 20 Watts |
| Power Requirement | 110 – 120V or 220 – 240VAC, 50/60 Hz; 24VDC |
| Dimensions | 133(H) x 483 (W) x 390 (D) mm |
| Built-in Dimensions | 3U Rack 19 inch |
| Net Weight | 7,1kg |
| Gross Weight | 8,4kg |
DSS-AMX16
Features:
- A powerfull Audio Matrix to multiple sources distribution with scheduled broadcast.
- Can be simulated in UI of DSS-CPCom and archieve central management through RS-485.
- 16 Audio input and audio outputs.
- With LCD display for convenient monitoring and controls.
- Priority bus for zone paging and emergency alarm.
Description
